Thermoplastic Hose Type 3/2

Part No : 00.70.1300 (10 m)

Part No : 00.70.1310 (15 m)

Part No : 00.70.1320 (20 m)

Applications

Waterblast : Heat exchanger tube cleaning. Pressure test equipment (valves, tooling and control panels),

Hydraulics : Hydraulic tools (instrumentation packages for gauges, control of service equipment, hydraulic jacks, hydraulic tools)

Max. Working Pressure : 1000 bar

Inner Diameter : 3.4 mm

Outer Diameter : 6.9 mm

Lenght : 10, 15, 20 m

Pdf File

*Safety factor between burst pressure and working pressure as well as test pressure depends on operating conditions. For gaseous media a safety factor of 1:6 is to be applied and the outer cover is to be pricked. The indicated working pressure refers to the hos only. Depending on the used fitting the permitted working pressure of a hose assembly can be less.
Inner Diameter	Outer Diameter	Working Pressure *	Burst Pressure	Bend Radius	Weight	Inner Diameter of Insert	Outer Cover Material	Outer Cover Diameter
ø mm	ø mm	bar	bar	mm	kg/m	ø mm		ø mm
3.4	6.9	1000	2500	60	0.072	2	Carbon Steel	8.9
