High Pressure Pump Lists

We keep our small and big type high pressure pumps in stock. You can see all our small and big type high pressure pump models in our stock, together with their technical specifications, in the lists below. Clean water is used in our big type high pressure pump models.

Contact us let us know your problems/needs, and we will determine the most suitable high pressure pumps for your needs.

Contact Us:   (+90) 312 394 12 70      (+90) 532 471 29 58      eb@ebsujeti.com.tr

High Pressure Pump List (Small Type)

Max. Flow Rate : 4-154 l/min

Max. Pressure : 100-1000 bar

Max. Power : 0-37 kW

Weight : 5.3-58.9 kg

Specifications
  • Splash lubrication
Pdf File

High Pressure Pump List (Small Type)

We keep our small type high pressure pumps in stock. You can see all our small type high pressure pump models in our stock, together with their technical specifications, in the list below.

Model Max. Pressure Flow Rate Power at Max. Pressure RPM Lubrication Weight
Bar (l/min) (kW) (Kg)
U-0.75/15 100 4 0.75 1450 Splash lubrication 5.3
U-1.1/15 100 6 1.1 1450 Splash lubrication 5.3
U-2.2/15 110 9 2.2 1450 Splash lubrication 5.3
U-5.5/18 200 15 5.5 1450 Splash lubrication 9.1
U-7.5/18 280 13 7.5 1450 Splash lubrication 10.5
U-11/26 200 30 11 1450 Splash lubrication 14.8
U-11/22 350 17 11 1450 Splash lubrication 17.4
U-15/22 400 19 15 1450 Splash lubrication 24.1
U-15/15 500 16 15 1450 Splash lubrication 21.1
U-15-50/83 100 84 15 600 Splash lubrication 53.3
U-18.5/18 500 20 18.5 1450 Splash lubrication 21.1
U-22/28 150 75 22 1450 Splash lubrication 30.4
U-30/16 500 30 30 1450 Splash lubrication 44.5
U-37/40 130 157 37 1000 Splash lubrication 58.2
U-37/500 500 40 37 1000 Splash lubrication 66
U-37/800 800 25 37 1000 Splash lubrication 60
U-37/1000 1000 20 37 1000 Splash lubrication 58.9
High Pressure Pump List (Big Type)

Max. Flow Rate : 17.2-277 l/min

Max. Pressure : 500-2800 bar

Max. Power : 45-250 kW

Weight : 400, 500 ,700 kg

Specifications
  • Splash lubrication
Pdf File

High Pressure Pump List (Big Type)

We keep our big type high pressure pumps in stock. You can see all our big type high pressure pump models in our stock, together with their technical specifications, in the list below.

Model Max. Pressure Flow Rate Power at Max. Pressure RPM Weight
(Bar) (l/min) (kW) RPM ø (mm) (Kg)
A-75/1 500 66 75 1500 26 400
A-75/2 750 56 75 1500 24 400
A-75/3 1000 39 75 1500 20 400
A-75/4 1400 28.4 75 1500 18 400
A-75/5 2500 17.2 75 1500 14 400
B-110/1 500 120 110 1500 35 400
B-110/2 750 76 110 1500 28 400
B-110/3 1000 56 110 1500 24 400
B-110/4 1500 35 110 1500 20 400
B-110/5 2000 28.4 110 1500 18 400
B-110/6 2500 22.5 110 1500 16 400
C-130/1 560 120 130 1500 35 400
C-130/2 750 88 130 1500 30 400
C-130/3 1000 66 130 1500 26 400
C-130/4 1400 47 130 1500 22 400
C-130/5 2000 33 130 1500 18 400
C-130/6 2500 26 130 1500 16 400
D-160/1 800 101 160 1500 30 500
D-160/2 1470 55 160 1500 22 500
D-160/3 2500 33 160 1500 18 500
E-250/1 500 277 250 1500 50 700
E-250/2 750 177 250 1500 40 700
E-250/3 1000 136 250 1500 35 700
E-250/4 1400 100 250 1500 30 700
E-250/5 2800 40 250 1500 20 700
